Product Name:Mootooh Piezo-electrice Printer MT-18S1

Product Details:

Model:: MT-J18S1

Select Payment and Shipping Terms:

Min. Order Quantity:: 1 Set/Sets

FOB Price:: USD 0.00-4000.00 /Set

Shippment Port:: CHINA PORTS

Payment Terms:: T/T,Western Union

Show Buyers your Ability to Supply:

Production Capacity:: 20 Set/Sets per Day

Delivery Time:: 10 working days after your full payment

Packaging:: Wooden cases

Detailed Product Description:

Mootooh Piezo-electrice Printer MT-18S1

1.Double four-color printing mode makes sure the output of vivid and bright color.

2.New “one-key” storage function realizes the printing parameters storage for different types of media, simplifying the repeated operation. Only need choosing the corresponding mode when printing again.

3.Hardware Configuration: Ultra silent guide rail with international quality;Custom made linear servo motor.

TECHNICAL PARAMETERS

Model

MT-18S1

Print Head

Piezo-electric print head DX5

Number of Print Head

One

Maximum Print Width

1600mm

Printing Precision

360×360 360×720 360×1080 720×720 720×1080 1440×1440（dpi）

Printing Speed

Production Mode: 4 pass

16㎡/hr

Quality Mode: 6 pass

11㎡/hr

Precision Mode: 8 pass

8㎡/hr

High Precision Mode:16 pass

4㎡/hr

Ink

Type

Eco-solvent ink

Color

（K、C、M、Y）

Capacity

440ml for each ink tank

Ink Supply System

Block brake type of ink supply system

Media

Width

1800mm

Type

Coated paper, Light box cloth, Wallpaper, Car stickers, Outdoor PP, PVC film, etc.

Print Head Height

1.5-3mm above media (adjustable)

Heating System

Embedded intelligent front heating system (the mid and back heating modes are optional)

Media Adsorption System

Several phase of intelligent air draft (Adjustable)

Auto Media System

Equipped (Max. Media Weight 40kg)

Auto Cleaning of Print Head

Owning anti-blocking, auto flash & moisturizing function

Clamp

Equipped

Auto Media Collecting System

Selectable

Printing Interface

USB2.0

RIP Software

Maintop、Photoprint (Optional)

Input Power

AC220V,50Hz/60Hz

Machine Size

2600×670×1350mm（L×W×H）

Other Products from this Supplier

+See more...

Model	MT-18S1
Print Head	Piezo-electric print head DX5
Number of Print Head	One
Maximum Print Width	1600mm
Printing Precision	360×360 360×720 360×1080 720×720 720×1080 1440×1440（dpi）
Printing Speed	Production Mode: 4 pass	16㎡/hr
	Quality Mode: 6 pass	11㎡/hr
	Precision Mode: 8 pass	8㎡/hr
	High Precision Mode:16 pass	4㎡/hr
Ink	Type	Eco-solvent ink
	Color	（K、C、M、Y）
	Capacity	440ml for each ink tank
	Ink Supply System	Block brake type of ink supply system
Media	Width	1800mm
	Type	Coated paper, Light box cloth, Wallpaper, Car stickers, Outdoor PP, PVC film, etc.
Print Head Height	1.5-3mm above media (adjustable)
Heating System	Embedded intelligent front heating system (the mid and back heating modes are optional)
Media Adsorption System	Several phase of intelligent air draft (Adjustable)
Auto Media System	Equipped (Max. Media Weight 40kg)
Auto Cleaning of Print Head	Owning anti-blocking, auto flash & moisturizing function
Clamp	Equipped
Auto Media Collecting System	Selectable
Printing Interface	USB2.0
RIP Software	Maintop、Photoprint (Optional)
Input Power	AC220V,50Hz/60Hz
Machine Size	2600×670×1350mm（L×W×H）
